Veris Industries TWXWXX SERIES Datasheet - Manual (Page 2)

wireless de
vices
800.354.8556 +1 503.598.4564 www.veris.com
APPLICATION/WIRING DIAGRAMS
DIMENSIONAL DRAWING
HQ0003916.B 03131
3.5"
(89 mm)
4.8"
(121 mm)
1.2"
(30 mm)
ORDERING INFORMATION
JACE Controller
EU
HW
Local Display
= No Display
Wireless
= Wireless
W
RH Option
1 = RH 1% NIST
2 = RH 2% NIST
H = RH 2%
Temp. Option
X = No temp.
T = Temp. transmitter
X
TW
Local Display
= No Display
Wireless
= Wireless
W X XX
NWGWA2 (Network Wireless Gateway) HWXWxx/TWXWXX Generic/Corporate WI-FI Router
enables device communication
Option 1: Integration to Building Control Using a Network Wireless Gateway
HWXWxx/TWXWXX Generic/Corporate WI-FI Router
enables device communication
Option 2: Direct Integration Using a JACE Controller
Building Server
DDC Controller
ACCESSORIES
Programming Cable (AWB01)
