Cables
Highly Flexible, Resists Bends
and Kinks, Abrasion Resistant
FEATURES
●
Strong, durable, and abrasion resistant
●
Expansion with mating end connectors...easy installation
●
Available in pre-measured and custom lengths with pre-installed end
connectors...installation flexibility
●
Plenum rated and UL listed
●
Highly accurate alarm notification...no false alarms
●
SC, SC-C, and SC-H cables detect the presence of specific fluids...application
versatility
DESCRIPTION
Sensing and non-sensing cables are designed for use with Zone and Distance Read
panels. The sensing cables detect the presence of liquid, and send a signal to the
panel. The panel generates an alarm and pinpoints the exact location of the leak or
spill along the cable’s length. Sensing cables are designed for the highest accuracy
and maximum reliability.
SC water detection cable senses the presence of water or other conductive fluid. SC-C
chemical sensing cable detects the presence of chemicals (see Specifications for list).
SC-H hydrocarbon sensing cable locates hydrocarbons within 1 foot (0.33 m) of the
actual leak, with as little as 2 inches (51 mm) of wetted cable, and is impervious to
the presence of water.
NSC non-sensing cable is used to extend the control panel’s leader cable to an area
where SC detection cable is needed. It also bridges lengths of SC detection cable in
areas where sensing is not required. Invisible to the control panel, the non-sensing
cable does not affect the accuracy of readings or limit the amount of water detection
cable that can be connected to a control panel. NSC cables are only compatible with
systems using SC water detection cables.
All cables are highly flexible, durable, and kink-resistant. They lie flat after
installation, and they are abrasion resistant. The cables are plenum rated and UL
listed making them ideal for use under raised floors and areas where plenum rated
cable is required. Choose a pre-specified cable length or a custom length for your
convenience and installation flexibility.
SPECIFICATIONS
Plenum Rating
SC: CL2P/CMP C(UL); NSC: CL3P/CMP C(UL) California State Fire Marshall approved
Shear Strength
SC/NSC: >180 lbs (>81.65 kg); SC-C: 160 lb (72.6 kg)
Cut Through Resistance
SC/NSC: >40 lbs (>18.2 kg) with 0.005” (0.13 mm) blade; SC-C: >50 lbs (>27.7 kg) with 0.005” (0.13 mm) blade
Abrasion Resistance
SC/NSC: 60 cycles per UL 719; SC-C: >65 cycles per UL719
Connector
SC/NSC: 4 pin, 1” (25.4 mm) diameter, circular, locking, 4 pin; SC-C: 0.5” (13 mm) diameter
Operating Environment:
Temperature
SC/NSC: 0° to 75°C (32° to 167°F); SC-C: 90°C (194°F) max.; SC-H: -20° to 90°C (-4° to 140°F)
Humidity
SC/NSC: 5% to 95% RH non-condensing
Altitude
SC/NSC: 10,000 ft. (3,048 m) max.
Storage Environment
SC: -30° to 85°C (-22° to 185°F); NSC: 0° to 75°C (32° to 167°F)
Standard Lengths:
SC-10/NSC-10
10 ft. (3.1 m)
SC-25/NSC-25
25 ft. (7.7 m)
SC-50/NSC-50
50 ft. (15.3 m)
SC-100/NSC-100
100 ft. (30.5 m)
Weight
0.02 lbs/ft (29.7 g/m)
Chemical Resistance, SC-C*
In accordance with ASTM D543, cable functions normally after seven days’ exposure to the following:
Fresh deionized water, tap water, sulfuric acid (98%), sulfuric acid (50%), hydrochloric acid (37%),
sodium hydroxide (10%), aqua regia, ethylene glycol (60% in DI water)
Chemical Resistance, SC-H*
In accordance with ASTM D543, cable functions normally after seven days’ exposure to the following:
Unleaded gasoline, #1 diesel fuel, #2 diesel fuel, JP5 jet fuel, JP8 jet fuel, Jet-A jet fuel, xylene, kerosene, cigarette lighter fuel (completely water resistant)
Agency Approvals
SC: CE; UL E162948; RoHS compliant
NSC: UL E118871; UL 13, power limited circuit cable; UL 444, communication cables; NFPA 262; plenum flame test (UL 910); NEC Articles 725 and 800; RoHS compliant
* Prolonged exposure to concentrated ketones may cause temporary reduction of sensitivity; call for details.
SC
NSC
SC, SC-C, SC-H, & NSC
SC-C
SC-H
