Veris Industries 381 IR Install User Manual
Pocket digital thermometer

Pocket Digital Thermometer
To measure temperature with this unit follow there simple
instructions:
Press the ON button to power on and take measurements. Unit will
automatically shut off after 30 seconds.
Changing C/F: Press On/Set key and press °F/°C button once to
flach °F or twice to flash °C annunciator on LCD. Press ON button to
set °C or °F.
OTM (One Time Measurement): Press and release ON button and
press °F/°C three time to display OTM annunciator on LCD. Press
and release ON button to display temperature on LCD. Reasding is
held on display for 10 seconds. Ideal for hard to reach lications.
Low Battery Indicator: Will be displayed when battery level
becomes less than 2.65 Volts.
HI and LO: Will be displayed when outside measurement range.
Specifications:
Range
-7° to 248°F or -22° to 120°C
Operating Temp
32° to 104°F or 0° to 40°C
Accuracy 2%
or
reading or +2°C, whichever is greater
Response Time
Less than 0.5 second
Resolution
0.1 °F/C
Emmissivity
0.95 fixed
Distance to Spot Ratio 1:1.3
Battery A003
Battery Life
50 hours continuous use, auto off after 30 sec.
THIS INSTRUMENT is in compliance with EN 50 081-1: 1992, EN 50
082-1:1992, IEC 801-2:1984, IEC 801-3:1984, IEC 801-4:1988
Test Products International, Inc.
Beaverton, OR 97005
503-520-9197 Fax: 503-520-1225
email: [email protected]
