V645
INSTALLATION GUIDE
N.C.
Common
24VAC/DC
120VAC
HI
wht/black
LOW
wht/blue
COMM
wht/yellow
Common
N.O.
CONTACT OUTPUT
CONTROL SYSTEM INPUT
White
YELLOW
White
White
ORANGE
blac
k
blac
k
blue
blue
yello
w
yello
w
blac
k
WIRING EXAMPLE
WIRING COLOR CODES
CONTACT AND COIL SPECIFICATIONS
Voltage
Coil Current
AC
DC
24-30V................................. 32mA
13mA
120V......................................
17mA
—
TYPICAL COIL PERFORMANCE
Resistive................. 10A@250VAC, N.O.
7A@250VAC, N.C.
6A@277VAC
7A@30VDC
Motor..................... 125VAC, 1/4 HP, N.0.
CONTACT RATINGS
V645
To Load
24V
120V
DIGITAL
CONTROL
PANEL
Coil
V645
To Load
24V
120V
POWER
SOURCE
PANEL
Coil
