800.354.8556 +1 503.598.4564 www.veris.com
DIMENSIONAL DRAWINGS
APPLICATION/WIRING DIAGRAMS
HN Series
HP Series
US or EU Temp.
Sensor Type
Accuracy NIST
S = Standard
C = CE
T = Temp
X = No Temp
(Stop here)
B = 100R Platinum, RTD
C = 1k Platinum, RTD
D = 10k T2, Thermistor
E = 2.2k, Thermistor
F = 3k, Thermistor
G = 10k CPC,Thermistor
H = 10k T3, Thermistor
J = 10k Dale, Thermistor
K = 10k with 11k shunt, Thermistor
M = 20k NTC, Thermistor
N = 1800 ohm TAC, Thermistor
Q = 1uA/˚C, Linitemp
R = 10k US, Thermistor
S = 10k 3A 221, Thermistor
T = 100k, Thermistor
U = 20k “D”, Thermistor
W = 10k T2 high accuracy, Thermistor
Y = 10k T3 high accuracy, Thermistor
Z = 10k E1, Thermistor
Output
M = 4-20mA
V = 0-5V/0-10VDC
N = NIST
1%, & 2% only
X = None
2%, 3%, 5% only
1 = 1%
2 = 2%
3 = 3%
5 = 5%
N = RH Insertion
P = RH Pendant
Enclosure
H Temp Cert OPTION
Example: (No Temp)
H P 2 X V S X
Example: (With Temp)
H N 2 X V S T C 2
Sensor Type Range
= Transmitter
Temp Cert
Blank = None
1 = 1pt Cal
2 = 2pt Cal
OPTION
1 = -40° - 122°F
(-40° - 50°C)
2 = 32° -122°F
(0° - 50°C)
Humidity Transmitter Combination
Humidity RTD/Thermistor Combination
Blank = None
1 = 1pt Cal
2 = 2pt Cal
HN/HP 0-5V/0-10V Versions HN/HP with RTD/Thermistor0-5V/0-10V Versions
HN/HP 4-20mA Versions HN/HP with RTD/Thermistor 4-20mA Versions
A
ACCESSORIES
Replacement humidity element (HS)
ORDERING INFORMATION
Available
Stop Here
POWER SUPPLY
24 VDC
BLK
RED
BLUE 0-10V HUMIDITY
ORANGE 0-10V TEMP
GREEN 0-5V HUMIDITY
YELLOW 0-5V TEMP
–
+
POWER SUPPLY
12 to 24 VDC
DIGITAL CONTROL
Temperature
4-20mA Return
(optional)
Humidity
4-20mA Return
BLUE
HUMIDITY
BLUE
HUMIDITY
White/Gray 0-1V
Test Leads for use
with voltmeter
ORANGE
Thermistor
ORANGE
Thermistor
+
–
–
POWER SUPPLY
12 to 24 VDC/24 VAC
BLK
RED
BLUE 0-10V HUMIDITY
GREEN 0-5V HUMIDITY
ORANGE THERMISTOR
ORANGE THERMISTOR
–
+
POWER SUPPLY
24 VDC only
DIGITAL CONTROL
Temperature
4-20mA Return
(optional)
Humidity
4-20mA Return
BLUE
HUMIDITY
BLUE
HUMIDITY
White/Gray 0-1V
Test Leads for use
with voltmeter
ORANGE
TEMP
ORANGE
TEMP
+
–
–
10"
(254 mm)
3.5"
(89 mm)
0.5" Dia.
(13 mm)
Foam Gasket
2.5" x 2.5"
(64 mm x 64 mm)
8.0"
(203 mm)
36"
(914 mm)
10.0"
254 mm
0.5" Dia.
13 mm
36"
914 mm
HS
HQ0001793.B 01131
