SPECIFICATIONS
Sensor Power
Induced from monitored conductor
Response Time
1 sec.
Accuracy
±2% of full scale
Frequency Range
50/60 Hz
Temperature Range
-15° to 60°C (5° to 140°F)
Humidity Range
10-90% RH non-condensing
LCD Backlight
Off at low currents; illuminates when monitored current exceeds 4.5A;
flashes during an alarm state while current remains above 4.5A
On-State Resistance
≤1.0 Ω
Off-State Resistance
≥1.0 MΩ
Setpoint Target Range, Switch Setting A*
±40% of learned nominal current; max. learned current of 142A to enable an upper trip limit at or below 200A
Setpoint Target Range, Switch Setting B*
±60% of learned nominal current;max. learned current of 125A to enable an upper trip limit at or below 200A
Switch Setting C*
On/Off Status; contacts are closed while amperage is above 2.5A
Alarm Reset Range
±5% of learned nominal current **
Setpoint Calibration Learn Period
30 sec.; self-learning, pushbutton reset
Normal-to-Alarm Output Delay
1 sec. maximum
Alarm-to-Normal Output Delay
30 sec. nominal
Insulation Class
600VAC RMS (UL); 300VAC RMS (CE)
Terminal Block Wire Size
24-14 AWG (0.2 to 2.1 mm
2
)
Terminal Block Torque
3.5 to 4.4 in-lbs (0.4 to 0.5 N-m)
Agency Approvals
UL508 open device, CE: EN61010-1:2001-02, CAT III, pollution degree 2
* Trip point switch positions A and B are not for use in applications where the current will fluctuate by more than 40% (A) or 60% (B) of the nominal current. If the current will fluctuate by more than 60%, use the H11D for on/
off status (position C) only.
** The upper trip limit alarm resets when the current drops by 5% of the learned nominal current limit. The lower trip limit alarm resets when the current rises by 5% of learned nominal current limit.
Specification Note: For CE compliance, conductor shall be insulated according to IEC 61010‑1:2001.
The product design provides for basic insulation only.
Do not use the LCD as evidence of applied voltage.
DESCRIPTION
The Hawkeye TruStat H11D is a microprocessor based, self-learning, self-calibrating
current switch. It is designed for user ease, providing calibration-free status for
both under and overcurrent, an LCD display, and slide-switch selectable trip point
limits. At initial power-up, the H11D automatically learns the average current on the
line with no action required by the installer. Once a current is learned, the switch
monitors for changes in current greater than the selected range.
APPLICATIONS
●
HVAC fans, pumps, and blowers
●
Monitoring status of industrial process equipment
FEATURES
●
Backlit LCD display...view the monitored current (up to 200A)...eliminates the
need for expensive handheld meters and offers easy visibility in dark enclosures
●
Automatic calibration...reduced errors and installation costs
●
Slide-switch selectable trip point limits...application versatility
●
Microcontroller based learning technology...automatically learns load upon
initial power-up...eliminates labor associated with calibration
●
Records and displays the amperage level that trips the alarm...simplifies
troubleshooting
●
Reset function can be used when unpowered...reduces the possibility of an
undesirable arc flash incident
●
Monitors current for both under- and over-load in one package
●
100% solid state...no moving parts to fail
●
Small size fits easily inside small starter enclosures...saves space
●
Self-gripping iris for easy installation
●
Bracket can be installed in three different configurations...added flexibility
●
5-year warranty
LCD Display
Current Switch:
Auto Calibration,
Automation Systems
Maximize Reliability
Minimize Installed Cost
Year
Warranty
5
H11D
H11D
