T SERIES INSTALLATION GUIDE
1.2"
(30 mm)
3.5"
(89 mm)
4.8"
(121 mm)
4.6"
(116 mm)
9.3"
(237 mm)
0.9"
(22 mm)
2.8"
(71 mm)
3.4"
(86 mm)
3.9"
(100 mm)
DIMENSIONS
TDDA
TOA
TWxA
8.5"
(216 mm)
0.5" Dia.
(13 mm.)
4.6"
(116 mm)
2.8"
(71 mm)
3.4"
(86 mm)
3.9"
(100 mm)
WIRING - TDDA AND TOA
POWER SUPPLY
12 To 30 VDC
DIGITAL CONTROL
Temperature
0-10V
+
–
–
Veris #PS-24
0-5V
RED
BLACK
ORANG
E
YELL
OW
POWER SUPPLY
12 To 30 VDC
DIGITAL CONTROL
Temperature
4-20mA return
+
–
–
ORANGE
ORAN
GE
Veris #PS-24
TDDA/TOA – 0-5/0-10V
TDDA/TOA – 4-20mA
POWER SOURCE
12 to 24VAC/DC
DIGITAL CONTROL
Temperature
0-5/0-10V
-
-
Thermistor
, RTD or O
ve
rrid
e Setpoint
Veris PS-24 Series, or Panel
+
RIGHT WIPER LEFT
-
POWER SOURCE
12 to 24VDC Only
DIGITAL CONTROL
Temperature
4-20mA
-
-
Thermistor
, RTD or O
ve
rrid
e
Setpoint
Veris PS-24 Series, or Panel
-
+
RIGHT WIPER LEFT
TWxA – 0-5/0-10V
TWxA – 4-20mA
NOTE: For 24 VAC transformer powered applications, connect one side of the transformer
secondary to the common. An isolation transformer or a dedicated power supply may be required.
WIRING - TWXA
32° to 122°F 50° to 95°F
0° to 50°C 10° to 35°C
Temp Range
10V 5V
Temp
°C °F
Temp
Volts
Output Select
mA
CONFIGURATION - TWXA
