V220
INSTALLATION GUIDE
WIRING EXAMPLE
Nipple mount directly to a panel
To Load
To Controls
COIL
CONT
ACTS
WIRING COLOR CODES
CONTACT AND COIL SPECIFICATIONS
Nipple mount to a 4x electrical box
Voltage
Coil Current
AC DC
24V.......................................... 75mA 32mA
208V........................................ 36mA
-
277V........................................ 49mA -
TYPICAL
COIL
PERFORMANCE
CONTACT RATINGS
Resistive.............. 20A@277VAC, 28VDC
Motor.................... 120VAC, 1HP
277VAC, 2HP
Pilot Duty............. A300
Ballast.................. 277VAC, 20A N.O.
277VAC, 10A N.C.
Tungsten............... 120VAC, 10A N.O.
120VAC, 2A N.C.
To Controls
POWER
SOURCE
Fractional
HP Motor
N.C.
Common
24VAC/DC
LOW
wht/blue
COMM
wht/yellow
Common
N.O.
CONTACT OUTPUT
CONTROL SYSTEM INPUT
White
YELLOW
White
ORANGE
blue
blue
yello
w
yello
w
208-277VAC
HI
wht/brown
White
brow
n
brow
n
