DESCRIPTION
The Veris VTD Series are multi-function time delay relays equipped with an external
control switch input and designed for easy socket/DIN mounting. The VTD2P-F50
includes five functions shown at left, while the VTD1P-UNI and VTD2P-UNI include
the same five as the VTD2P-F50 plus five more, for the most versatile relay available.
Save inventory costs by purchasing one relay for all the functions you need.
FEATURES
●
VTD2P-F50 has thumb wheel adjustment for function and timing...ensures
accuracy and eliminates mechanical deviation
●
VTD1P/2P-UNI models are made with solid state relays for greater reliability
●
Two different housings provide multiple mounting options
Multi-Function Time Delay Relays
For A Variety Of Applications
Time Delay Relays
SPECIFICATIONS
Operating Range
85% to 110% of nominal voltage
Drop-Out Voltage Threshold
15% of nominal voltage
Expected Relay Life
Electrical (resistive @ rated current) 100,000 cycles; Mechanical (unpowered) 10,000,000 cycles
Dielectric Strength
1000VAC RMS
Operating Temperature Range
-20°C to 55°C (-4 to 131°F)
Year
Warranty
5
Function
Timing Chart
RE-TRIGGERABLE
ONE SHOT
PULSE
GENERATOR
ON/OFF DELAY
(S Make/Break)
REPEAT CYCLE
(Starting On)
MEMORY LATCH
(S Make)
S
R
U
T
T
T
R
U
T
Pulse
T Pulse
R
U
T
T
T
T
T
S
R
U
S
R
U
T
T
T
T
T
T
U: Applied input voltage S: Control switch (open or closed)
R: Relay contacts (on or off)
T: Time delay
VTD2P-F50
VTD1P-UNI, VTD2P-UNI
Function
Timing Chart
ON DELAY
(Power On)
OFF DELAY
(S Break)
REPEAT CYCLE
(Starting Off)
INTERVAL
(Power On)
ONE SHOT
R
U
T
T
S
R
U
T
T
R
U
T
T
T
T
T
T
R
U
T
T
T
S
R
U
T
T
T
T
T
VTD2P-F50
VBD3P-C
VTD2P-UNI
Power Consumption
AC ...................................................... 2.5VA
DC...................................................... 2W
TYPICAL COIL PERFORMANCE
(VTD2P-F50)
Resistive ...........12A@240VAC, 30VDC
Pilot Duty..........B300
(VTD1P-UNI, VTD2P-UNI)
Resistive ...........15A@240VAC, 24VDC
Motor ...............1/2HP@120VAC; 1HP@240VAC
Pilot Duty ......... B300
CONTACT RATINGS
VTD2P-F50 VTD1P-UNI, VTD2P-UNI
TIMING CHARACTERISTICS
Funtions Available
5
10
Time Ranges
0.1 sec
0-999
1-10
sec
0-999
1-10
0.1 min
0-999
1-10
min
0-999
1-10
0.1 hr
0-999
1-10
hr
0-999
1-10
10 hr
0-999
---
0.1 day
---
1-10
day
---
1-10
Tolerance
0%
5%
(mechanical setting)
Repeatability
0.1%
0.2%
Operate Time
(max)
25ms
no spec
Reset Time
(max)
150ms
150ms
Trigger Pulse Length
(min) ---
50ms
