Veris Industries A8911–23 Datasheet - Manual (Page 2)

net
w
ork inte
gra
tion
800.354.8556 +1 503.598.4564 www.veris.com
DIMENSIONAL DRAWING
APPLICATION/WIRING EXAMPLE
ORDERING INFORMATION
3.4”
(86 mm)
4.2”
(106 mm)
1.2”
(31 mm)
MODEL MANUF. PART # DESCRIPTION
U013-0010 A8911-23 Pulse input module (up to 23 standard pulse devices)
RS-485
Modbus
Up to 23 standard
pulse output devices
A8911-23
H8163
with Comms Board
Option
Local PC
Modbus or Pulse Output
Energy Meters
(Veris H803x or H805x Enercept)
Branch Current
Power Meter
(Veris E30 or E31)
Data Acquisition Devices
(Veris H8822 or A8810)
HQ0001806.B 01131
