Electrical Testers
SPECIFICATIONS
275:
DC Voltage
600V range, 0.01mV max. res., ±0.5% basic accuracy
AC Voltage
600V range, 0.01mV max. res., ±0.5% basic accuracy
DC Amps
400A range, 0.01A max. res., ±0.8% basic accuracy
DC Microamps
1100μA range, 0.01μA max. res., ±3% basic accuracy
AC Amps
400A range, 0.01A max. res., ±3% basic accuracy
Frequency
110MHz range, 0.1Hz max. res., ±1% basic accuracy
Resistance
110MΩ range, 0.01Ω max. res., ±1% basic accuracy
Capacitance
110mF range, 0.001nF max. res., ±3% basic accuracy
Temperature
1000°F range, 0.1°F max. res., ±1% basic accuracy
440:
DC Voltage
400mV, 4, 40, 400, 1000V range, ±0.3% basic accuracy
AC Voltage
300mV, 3, 30, 300, 750V range, ±0.75% basic accuracy
DC Amps
400μA, 4000μA, 40mA, 400mA, 4A, 10A range, ±0.5% basic accuracy
AC Amps
300μA, 3000μA, 30mA, 300mA, 3A, 10A range, ±75% basic accuracy
Frequency
1Hz to 2MHz ±0.05% basic accuracy
Resistance
400Ω, 4kΩ, 40kΩ, 400kΩ, 4MΩ, 30MΩ ±0.3% basic accuracy
Capacitance
400nF, 4μF, 40μF, 400μF ±3% basic accuracy
196:
DC Voltage
1000V max. input, 0.0001V max. res., ±0.05% basic accuracy
AC Voltage
1000V max. input, 0.001V max. res., ±0.4% basic accuracy
DC Amps
1A max. input, 0.0001mA max. res., ±0.5% basic accuracy
AC Amps
1A max. input, 0.0001mA max. res., ±0.75% basic accuracy
Frequency
500kHz max. input, 0.01Hz max. res., ±0.05% basic accuracy
Resistance
50MΩ max. input, 0.01Ω max. res., ±0.05% basic accuracy
133:
DC Voltage
1000V max. input, 0.1mV max. res., ±0.5% basic accuracy
AC Voltage
750V max. input, 0.1mV max. res., ±0.8% basic accuracy
DC Amps
10A max. input, 0.1μA max. res., ±0.5% basic accuracy
AC Amps
10A max. input, 0.1μA max. res., ±1% basic accuracy
Resistance
20MΩ max. input, 0.1Ω max. res., ±0.5% basic accuracy
All products include a one year warranty on probes and leads, a two year warranty on sensors, and a three year warranty on meters.
275 Meter
●
Autoranging AC/DC amps
●
True RMS
●
11,000 count display with 41 segment analog bargraph
●
AC/DC voltage, amperage, resistance, capacitance, temperature and frequency
modes...full-featured meter in a compact, rugged package
440 Oscilloscope/Multimeter
●
1 MHz oscilloscope bandwidth
●
RS-232 for PC communication
●
Trending mode enables graphing of surges and dropouts
●
AC/DC volts, AC/DC amps, resistance, capacitance, and frequency modes
●
Integral true RMS 4000-count autoranging multimeter
196 Digital Multimeter
●
0-24mA DC output for simulating and testing process loop controls
●
50,000 count display with backlight...easy readability
●
RS-232 output
●
Autoranging
133 Basic Multimeter
●
Large, easy-to-read 2000-count backlit display
●
Data hold feature
●
Protective boot
●
AC/DC voltage, AC/DC amps, and resistance modes
440
133
196
275
275, 440, 196, & 133
