Rel ay s, Dimensional drawings application/wiring examples, Accessories – Veris Industries VST10 SERIES Datasheet User Manual
Page 2: Ordering information
REL
AY
S
800.354.8556
+1 503.598.4564
www.veris.com
*Coil side Hand-Off-Auto switch contained in low-voltage portion of input circuit
MODEL
RELAY
COIL
AMPERAGE RATING
HOA
LENGTH RELAY POWER LED
UL
VST10
SPDT
24VAC/DC
10A
No
2.75”
n
n
VST10-4
24VAC/DC
No
4.0”
n
n
VST11
24VAC/DC
Yes*
2.75”
n
n
VST11-4
24VAC/DC
Yes*
4.0”
n
n
VST100
10-30VAC/DC, 120VAC
No
2.75”
n
n
VST100-4
10-30VAC/DC, 120VAC
No
4.0”
n
n
VST101
10-30VAC/DC, 120VAC
Yes*
2.75”
n
n
VST101-4
10-30VAC/DC, 120VAC
Yes*
4.0”
n
n
DIMENSIONAL DRAWINGS
APPLICATION/WIRING EXAMPLES
VST 10 & VST 11
VST 100 & VST 101
VST 10-4 & VST 11-4
VST 100-4 & VST 101-4
2.75"
(70 mm)
1.1"
(28 mm)
0.9"
(23 mm)
3.7"
(94 mm)
4.0"
(102 mm)
1.1"
(28 mm)
0.8"
(25 mm)
Ø 0.15”
(4 mm)
0.9"
(23 mm)
ACCESSORIES
2” and 12” lengths of SNAPTRACK™
(AV03, AV04, AV05, AV06)
2.75"
(70 mm)
1.5"
(39 mm)
1.4"
(36 mm)
4.0"
(102 mm)
1.5"
(39 mm)
1.2"
(30 mm)
1.4"
(36 mm)
3.7"
(94 mm)
Ø 0.15”
(4 mm)
ORDERING INFORMATION
To
Load
24VAC/DC
POWER
SUPPLY
DIGITAL
CONTROLLER
CONTROL PANEL
24VAC/DC Aux HOA Switch Power
(some models only)
24VAC/DC
Coil Power
Relay
Contacts
E150462
AV03
AV04
AV05
AV06
HQ0001849.C 01131
