Veris Industries SCT SERIES Datasheet - Manual

P
O
WER Metering CT
S
VERIS INDUSTRIES
800.354.8556 +1 503.598.4564 www.veris.com
SCT
Low Current Ranges
DESCRIPTION
SCT AC current sensors have center hole sizes and current ratings to suit any
application. SCT models have a split-core that is perfect for retrofits. Output is fixed
at the industry standard of 0.333VAC.
APPLICATIONS
● Data logging
● Recording
● Power monitoring
● Energy management
● Alternative energy monitoring
● Cost allocation
Current Transducers,
Voltage Output
SPECIFICATIONS
Inputs:
Frequency Range 50-400 Hz
Leads 8 ft (204 m)
Accuracy:
Accuracy ±1% of reading from 10% to 130% of rated current
Outputs:
Output at Rated Current 0.333VAC
Mechanical:
Insulation 600VAC
Environmental:
Operating Temperature Range -10° to 55°C (14° to 131°F)
Storage Temperature Range -40° to 70°C (-40° to 158°F)
Agency Approvals cURus, CE, RoHS
Year
Warranty
3
SCT SERIES
FEATURES
● High accuracy: ±1% from 10% to 130% of rated current
● 0.333VAC standard output...compatible with existing systems
● Interleaving joints for reliability with a self-locking mechanism and no exposed
metal...safe design
● UL recognized
HQ0001819.B 01131
