V300 INSTALLATION GUIDE
WIRING COLOR CODES
CONTACT AND COIL SPECIFICATIONS
N.C.
Common
20-30VAC/DC
120VAC
HI
wht/black
LOW
wht/blue
COMM
wht/yellow
Common
N.O.
CONTACT OUTPUT CONTROL SYSTEM INPUT
White
YELLOW
White
White
ORANGE
blac
k
blac
k
blue blue
yello
w
yello
w
blac
k
N.C.
Common
N.O.
*Contact ratings are for single pole operation. When
operating both poles simultaneousley, the total load
cannot exceed the ratings above.
Pull in Voltage AC DC
20-30V..................................... 18 20
120V........................................ 104
Drop Out Voltage
AC DC
20-30V..................................... 4 5
120V........................................ 26
Voltage
Coil Current
AC DC
24V.......................................... 43mA 25mA
30V.......................................... 54mA 31mA
120V........................................ 29mA -
TYPICAL COIL PERFORMANCE
CONTACT RATINGS*
Resistive.............. 10A@277VAC, 30VDC
Motor.................... 120VAC, 1/8HP
WIRING EXAMPLE
Nipple mount directly to a panel
Nipple mount to a 2x or 4x electrical box
* Isolate any unused wires, e.g. wire nut.
To Load A
To Controls
CONTROL
PANEL
COIL
To Load B
To Power
COM
N.O.
N.C.
To Load B
To Control
Wire
Nuts CO
IL
CONTACTS
To Load A
To Power
N.C.
N.O.
COM
