INSTALLATION GUIDE
register listing
Offset Point Type Description
0 40001 UINT32 Pulse count 1 MSW
1 40002 UINT32 Pulse count 1 LSW
2 40003 UINT32 Pulse count 2 MSW
3 40004 UINT32 Pulse count 2 LSW (same format as pulse count 1)
4 40005 UINT16 InstPulse 1 time (seconds)
5 40006 UINT16 InstPulse 2 time (seconds)
6 40007 UINT16 (R/W) min. pulse 1 time (seconds) (write clears min./max.)
7 40008 UINT16 (R/W) min. pulse 1 time (seconds)
8 40009 UINT16 (R/W) max. pulse 2 time (seconds)
9 40010 UINT16 (R/W) max. pulse 1 time (seconds)
10 40011 UINT16 (R/W) InstPulse count size (default = 5)
100 40101 UINT16 Serial number (bytes 1, 2)
101 40102 UINT16 Serial number (bytes 3, 4)
102 40103 UINT16 Serial number (bytes 5, 6)
103 40104 UINT16 Firmware version (e.g. v1.03, high byte = major; low byte = minor; 0x8000 flag set for Beta)
104 40105 UINT16 Boot count
105 40106 UINT32 Mfg date MSW
106 40107 UINT32 Mfg date LSW
107 40108 UINT16 Radio group ID setting (0-6)
108 40109 UINT16 Alarm flags (0x01 = boot from watchdog)
109 40110 UINT16 Max. packet buffers used
110 40111 UINT32 Radio up time (seconds) MSW
111 40112 UINT32 Radio up time (seconds) LSW
