ENVIRONMENTAL SENSORS
INSTALLATION GUIDE
Wall Plate Remote Pickup for PX
AA56
AA56
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classified locations.
• Read and understand the instructions before installing
this product.
• Turn off all power supplying equipment before working on it.
• The installer is responsible for conformance to all applicable codes.
PRODUCT IDENTIFICATION
AA56 Remote pickup wall plate
INSTALLATION
1. Connect tubing between the fitting on
the PX sensor and the fitting on the
back of the AA56.
2. Mount the wall plate onto the wall in
the area to be monitored.
OPERATION
Use the AA56 with the PX series dry media differential pressure transducer when the
PX is not mounted in the area that needs to be monitored. Mount the AA56 in the
testing area and connect it to the PX with tubing.
