800.354.8556 +1 503.598.4564 www.veris.com
MODEL RELAY TYPE AMPERAGE RANGE COIL VOLTAGE MIN. SWITCHING CURRENT LED UL CE
VMD4B-C24D
4PDT 10A
24VDC
100mA@5VDC
n n
VMD4B-C24A 24VAC n n
VMD4B-C120A 120VAC n n
VMD4B-F24D 24VDC n n n
VMD4B-F24A 24VAC n n n
VMD4B-F120A 120VAC n n n
DIMENSIONAL DRAWINGS
VBD4B-C Socket
VBD4B-F Socket
VMD4B Relays
VBD4B Sockets
2.6"
(66mm)
1.8"
(46mm)
1.1"
(28mm)
2.0"
(51mm)
These relays are UL Listed, when used with the Veris sockets.
When relays and sockets are used together, amperage rating is the lesser of the two ratings.
MODEL AMPERAGE RATING VOLTAGE RATING FINGER SAFE HOLD DOWN CLIP UL CE
VBD4B-C 10A
300V
n n
VBD4B-F 16A n n n n
1.1”
(27 mm)
1.7”
(43 mm)
1.4”
(36 mm)
Hold Down Clip included
with F Model socket
2.0"
(51 mm)
3.1"
(80 mm)
1.1"
(28 mm)
14 (A2) 13 (A1)
TOP VIEW
Coil (+)**
Coil (-)**
COMM1
N.O.1
N.C.1
COMM2
N.O.2
N.C.2
COMM3
N.O.3
N.C.3
COMM4
N.O.4
N.C.4
Function
NEMA (IEC)*
Terminal
14 (A2)
13 (A1)
9 (11)
5 (14)
1 (12)
10 (21)
6 (24)
2 (22)
11 (31)
7 (34)
3 (32)
12 (41)
8 (44)
4 (42)
8(44) 7(34) 6(24) 5(14)
4(42) 3(32) 2(22) 1(12)
12(41) 11(31) 10(21) 9(11)
APPLICATION/WIRING EXAMPLE
** Observe polarity for relays with
DC coil voltages only
ORDERING INFORMATION
SOCKET ORDERING INFORMATION
ACCESSORIES
DIN Rail, Stop Clip (AV01, AV02)
RoHS
Compliant E198454
AV01 AV02
HQ0001854.B 01131
