65
Fastener Specifications
Note: Exact compliance with recommended torque values will
assure the best results.
Thread Size Identification Class Identification (Fastener Strength)
Strength (class) is identified by numbers on the bolt head or
nut face. Increasing numbers represent increasing strength.
Axle Model Pinion Nut
Part No. Washer Part
No. Thread Size Socket Size
15040 210133 210144 M30 x 1.5 41mm
19050 210133 210144 M30 x 1.5 41mm
19055 210089 210090 M36 x 1.5 55mm
17060 127589 not used M36 x 1.5 55mm
19060 127589 not used M36 x 1.5 55mm
21060 127589 not used M36 x 1.5 55mm
21065 210089 210090 M36 x 1.5 55mm
21080 128049 not used M36 x 1.5 55mm
21090 210089 not used M36 x 1.5 55mm
22060 127589 not used M36 x 1.5 55mm
22065 210089 210090 M36 x 1.5 55mm
23070 210508 210509 M42 x 1.5 55mm
23080 128049 not used M42 x 1.5 55mm
23085 128049 not used M42 x 1.5 55mm
23090 128049 not used M42 x 1.5 55mm
23105 95262 not used 1.75-12 2.25”
26080 128049 not used M42 x 1.5 55mm
26085 210508 210509 M42 x 1.5 55mm
26090 210508 210509 M42 x 1.5 55mm
26105 95262 not used 1.75-12 2.25”
30080 128049 not used M42 x 1.5 55mm
30105 95262 not used 1.75-12 2.25”
M12 X 1.75
Nominal
Diameter
(mm) Thread
Pitch (mm)
8.8 10.9
Bolts and cap screws
12.9
10
10 12
Nuts
12
