Spicer Illustrated Parts List Spicer Steer Axles - Manual (Page 71)

69
Axle Specifications E1302-E1322
STEER AXLE
ASSEMBLY PART NO.
I-BEAM
KNUCKLE
ASSY LH
ASSY RH
TIE ROD
ASSY
STOP SCREW
LH / RH
FRONT STEER
SPINDLE NUT
TURN
ANGLE
LH / RH
1322BN104-27 1462TB105-6 685236 971776 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN104-28 1462TB105-6 685238 971776 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN105-1 1462TB107-2 971931 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971837 . 816367 41°-45°
1322BN105-2 1462TB107-2 971935 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971839 816366 36°-40°
1322BN105-3 1462TB107-2 971937 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971833 816366 36°-40°
1322BN105-4 1462TB107-2 971952 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971954 816366 36°-40°
1322BN105-5 1462TB107-3 972043 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971100 816367 41°-45°
1322BN105-6 1462TB107-3 972093 971713 816367 1.50-18 UNEF-2A THD 41°-45°
972095 816367 41°-45°
1322BN105-7 1462TB107-6 972254 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972248 120HM101 30°-50°
1322BN105-8 1462TB107-6 972262 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972260 120HM101 30°-50°
1322BN105-9 1462TB107-6 972272 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972260 120HM101 30°-50°
1322BN105-10 1462TB107-8 972274 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972246 120HM101 30°-50°
1322BN105-11 1462TB107-8 972429 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972250 120HM101 30°-50°
1322BN105-12 1462TB107-6 972509 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972250 120HM101 30°-50°
1322BN105-13 1462TB107-7 971931 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971837 . 816367 41°-45°
1322BN105-14 1462TB107-7 971935 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971839 816366 36°-40°
1322BN105-15 1462TB107-7 971937 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971833 816366 36°-40°
1322BN105-16 1462TB107-7 971952 971713 816367 1.50-18 UNEF-2A THD 41°-45°
971954 816366 36°-40°
1322BN105-17 1462TB107-8 971986 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972246 120HM101 30°-50°
1322BN105-18 1462TB107-6 972256 971713 120HM101 1.50-18 UNEF-2A THD 30°-50°
972246 120HM101 30°-50°
