Spicer Illustrated Parts List Spicer Steer Axles - Manual (Page 67)

65
Axle Specifications E1302-E1322
STEER AXLE
ASSEMBLY PART NO.
I-BEAM
KNUCKLE
ASSY LH
ASSY RH
TIE ROD
ASSY
STOP SCREW
LH / RH
FRONT STEER
SPINDLE NUT
TURN
ANGLE
LH / RH
1322BN103-73 971674 972903 815326 816369 1.50-18 UNEF-2A THD 46°-50°
971100 816369 46°-50°
1322BN103-74 971674 972905 815326 816369 1.50-18 UNEF-2A THD 46°-50°
972286 816369 46°-50°
1322BN103-77 972174 972926 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972938 120HM101 30°-50°
1322BN103-78 972174 972929 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972939 120HM101 30°-50°
1322BN103-79 972174 972930 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972937 120HM101 30°-50°
1322BN103-80 972174 972925 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972938 120HM101 30°-50°
1322BN103-81 972174 972927 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972939 120HM101 30°-50°
1322BN103-82 972174 972928 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972937 120HM101 30°-50°
1322BN103-83 972174 973010 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
973026 120HM101 30°-50°
1322BN103-84 972174 973011 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
973027 120HM101 30°-50°
1322BN103-85 972174 973012 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
973025 120HM101 30°-50°
1322BN103-86 972174 973038 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
973054 120HM101 30°-50°
1322BN103-87 972174 973039 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
973055 120HM101 30°-50°
1322BN103-88 972174 973040 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
973053 120HM101 30°-50°
1322BN103-89 972174 972926 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972938 120HM101 30°-50°
1322BN103-90 972174 972929 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972939 120HM101 30°-50°
1322BN103-91 972174 972930 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972937 120HM101 30°-50°
1322BN103-92 972174 972925 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972938 120HM101 30°-50°
1322BN103-93 972174 972927 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972939 120HM101 30°-50°
1322BN103-94 972174 972928 815326 120HM101 1.50-18 UNEF-2A THD 30°-50°
972937 120HM101 30°-50°
