59
Axle Specifications E1302-E1322
STEER AXLE
ASSEMBLY PART NO.
I-BEAM
KNUCKLE
ASSY LH
ASSY RH
TIE ROD
ASSY
STOP SCREW
LH / RH
FRONT STEER
SPINDLE NUT
TURN
ANGLE
LH / RH
1322BN101-70 1462TB102-11 973230 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN101-71 1462TB102-11 973210 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN101-72 1462TB102-11 973234 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973280 120HM101 30°-50°
1322BN101-73 1462TB102-11 973232 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN101-74 1462TB102-11 973216 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN101-75 1462TB102-11 973212 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973280 120HM101 30°-50°
1322BN101-76 1462TB102-11 973230 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN101-77 1462TB102-11 973210 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN101-78 1462TB102-11 973238 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973280 120HM101 30°-50°
1322BN101-79 1462TB102-11 973248 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN101-80 1462TB102-11 973236 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN101-81 1462TB102-11 973252 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973280 120HM101 30°-50°
1322BN101-82 1462TB102-11 973260 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN101-83 1462TB102-11 973250 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN101-84 1462TB102-11 973462 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973464 120HM101 30°-50°
1322BN101-85 1462TB102-11 973466 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973468 120HM101 30°-50°
1322BN101-86 1462TB102-11 685228 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973280 120HM101 30°-50°
1322BN101-87 1462TB102-11 685230 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973282 120HM101 30°-50°
1322BN101-88 1462TB102-11 685232 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973278 120HM101 30°-50°
1322BN101-89 1462TB102-11 685234 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
973280 120HM101 30°-50°
