Steer Axle Components
E-1000I,W, E-1200I,W, E-1201W, E-1320I,W, E-1460I,W
SINGLE DRAW KEY DESIGN (Ended Production in 2005)
Qty E1200I,W E1460I,W
Item Description Per Axle E1000I,W E1201W E1320I,W Pre 1/1/00 After 1/1/00 Notes
King Pin Kits
Kit w/Steel Backed Acetal Bushing (DX) 1 328344 328344 328344 329404 328345 See Note 1
Kit w/Bronze Bushing 1 328342 328342 328342 329405 328343 See Note 1
1 Drawkey Locknut 2 067592 or 1004804 All Models,;
TCA Hex [1/2] 20 UNF
2 Seal (Knuckle) 4 815237 815237 815237 820518 820518
3 Shims .005" A/R 817493 All Models
.010" A/R 817494 All Models
.030" A/R 817492 All Models
4 Drawkeys 2 816239
5 Thrust Bearing 2 815285 815285 815285 811523 220HC104
6 Beam 1 Refer to ID tag on assembly
7 Stop Screw Turn Angle 2
30-35 degree A/R 816365 All Models
36-40 degree A/R 816366 All Models
41-45 degree A/R 816367 All Models
46-50 degree A/R 816369 All Models
51-55 degree A/R 816370 All Models
8 Stop Screw Nut 2 090208 All Models
9 Cross Link Assembly 1 See page 12
10 Tie Rod Ends 2 See pages 12-13
11 Jam Nut - Outer 2 815638 All Models
12 Retainer Washer 2 817134 All Models
13 Spindle Washer 2 815623 All Models
14 Jam Nut Inner 2 815622 All Models
15 PRO TORQ® Nut Assy 2 128333 All Models; See Note 2
16 Grease Fitting 4 819790 All Models
17 Knuckle Cap 4 971370 All models,;
Replaced 816295
18 Foam Insert 4 971010 All Models
19 Bushing Steel Backed Acetal (DX) 4 1320HD101 1320HD101 1320HD101 806334 806334
Bronze 4 1320HD100 1320HD100 1320HD100 1460HD100 1460HD100
20 Knuckle Pin 2 815284 815284 815284 817452 817452 See Note 1
21 Knuckle Assy 2 Refer to ID tag on assembly
22 Cotter Pin (Tie Rod Nut) 2 HP102 All Models;
Replaced 1004805
NOTE 1: 1/1/00 Design change to E1460; See Bulletin ABIB-0212
NOTE 2: Pro Torq is a registered trademark of Caromet Inc.
