Axle Specifications E1302-E1322
STEER AXLE
ASSEMBLY PART NO.
I-BEAM
KNUCKLE
ASSY LH
ASSY RH
TIE ROD
ASSY
STOP SCREW
LH / RH
FRONT STEER
SPINDLE NUT
TURN
ANGLE
LH / RH
1322BN102-18
1462TB103-5
973434
971092
120HM101
1.50-18 UNEF-2A THD
30°-50°
973278
120HM101
30°-50°
1322BN102-19
1462TB103-5
973454
971092
120HM101
1.50-18 UNEF-2A THD
30°-50°
973398
120HM101
30°-50°
1322BN102-20
1462TB103-5
685204
971092
120HM101
1.50-18 UNEF-2A THD
30°-50°
973398
120HM101
30°-50°
1322BN102-21
1462TB103-5
971251
971092
816369
1.50-18 UNEF-2A THD
46°-50°
DUAL STEER
972597
816369
46°-50°
1322BN102-22
1462TB103-5
685270
971092
120HM101
1.50-18 UNEF-2A THD
30°-50°
973280
120HM101
30°-50°
1322BN102-23
1462TB103-5
685306
971092
120HM101
1.50-18 UNEF-2A THD
30°-50°
973280
120HM101
30°-50°
1322BN102-24
1462TB103-8
973124
971092
120HM101
1.50-12 UNF-2A THD
30°-50°
973142
120HM101
30°-50°
1322BN102-25
1462TB103-8
973088
971092
120HM101
1.50-12 UNF-2A THD
30°-50°
973138
120HM101
30°-50°
1322BN103-1
971805
971789
815326
816369
1.50-18 UNEF-2A THD
46°-50°
971791
816369
46°-50°
1322BN103-2
971805
971802
815326
816369
1.50-18 UNEF-2A THD
46°-50°
971804
816369
46°-50°
1322BN103-3
971620
971923
815326
816369
1.50-18 UNEF-2A THD
46°-50°
971837
816369
46°-50°
1322BN103-4
971620
971927
815326
816369
1.50-18 UNEF-2A THD
46°-50°
971829
816369
46°-50°
1322BN103-5
971620
971929
815326
816369
1.50-18 UNEF-2A THD
46°-50°
971833
816369
46°-50°
1322BN103-6
971620
971931
815326
816367
1.50-18 UNEF-2A THD
41°-45°
971837
816367
41°-45°
1322BN103-7
971620
971935
815326
816367
1.50-18 UNEF-2A THD
41°-45°
971839
816366
36°-40°
1322BN103-8
971620
971937
815326
816367
1.50-18 UNEF-2A THD
41°-45°
971833
816366
36°-40°
1322BN103-9
971620
971933
815326
816367
1.50-18 UNEF-2A THD
41°-45°
971837
816367
41°-45°
1322BN103-10
971620
971939
815326
816367
1.50-18 UNEF-2A THD
41°-45°
971839
816366
36°-40°
1322BN103-11
971620
971941
815326
816367
1.50-18 UNEF-2A THD
41°-45°
971833
816366
36°-40°
1322BN103-12
971959
971956
815326
816366
1.50-18 UNEF-2A THD
36°-40°
971958
816366
36°-40°
