Axle Specifications E1302-E1322
STEER AXLE
ASSEMBLY PART NO.
I-BEAM
KNUCKLE
ASSY LH
ASSY RH
TIE ROD
ASSY
STOP SCREW
LH / RH
FRONT STEER
SPINDLE NUT
TURN
ANGLE
LH / RH
1322BN101-30 1462TB102-11 972680 971092 816369 1.50-18 UNEF-2A THD 46°-50°
817737 816369 46°-50°
1322BN101-31 1462TB102-10 972495 971092 816367 1.50-18 UNEF-2A THD 41°-45°
818060 816366 36°-40°
1322BN101-32 1462TB102-10 817723 971092 816369 1.50-18 UNEF-2A THD 46°-50°
817738 816369 46°-50°
1322BN101-33 1462TB102-11 970902 971092 816369 1.50-18 UNEF-2A THD 46°-50°
817744 816369 46°-50°
1322BN101-34 1462TB102-10 972495 971092 816367 1.50-18 UNEF-2A THD 41°-45°
818060 816366 36°-40°
1322BN101-35 1462TB102-11 972844 971092 816367 1.50-18 UNEF-2A THD 41°-45°
817744 816367 41°-45°
1322BN101-36 1462TB102-11 972846 971092 816367 1.50-18 UNEF-2A THD 41°-45°
818060 816367 41°-45°
1322BN101-37 1462TB102-11 972848 971092 816367 1.50-18 UNEF-2A THD 41°-45°
817738 816367 41°-45°
1322BN101-38 1462TB102-11 972850 971092 816367 1.50-18 UNEF-2A THD 41°-45°
817744 816367 41°-45°
1322BN101-39 1462TB102-11 972852 971092 816367 1.50-18 UNEF-2A THD 41°-45°
818060 816367 41°-45°
1322BN101-40 1462TB102-11 972854 971092 816367 1.50-18 UNEF-2A THD 41°-45°
817738 816367 41°-45°
1322BN101-41 1462TB102-11 970902 971092 816367 1.50-18 UNEF-2A THD 41°-45°
817744 816367 41°-45°
1322BN101-42 1462TB102-11 972497 971092 816367 1.50-18 UNEF-2A THD 41°-45°
818060 816367 41°-45°
1322BN101-43 1462TB102-11 970904 971092 816367 1.50-18 UNEF-2A THD 41°-45°
817738 816367 41°-45°
1322BN101-44 1462TB102-11 972940 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
972934 120HM101 30°-50°
1322BN101-45 1462TB102-11 972932 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
972935 120HM101 30°-50°
1322BN101-46 1462TB102-11 972924 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
972933 120HM101 30°-50°
1322BN101-47 1462TB102-11 972921 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
972934 120HM101 30°-50°
1322BN101-48 1462TB102-11 972931 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
972935 120HM101 30°-50°
1322BN101-49 1462TB102-11 972920 971092 120HM101 1.50-18 UNEF-2A THD 30°-50°
972933 120HM101 30°-50°
