Spicer Illustrated Parts List Spicer Steer Axles - Manual (Page 11)

9
Steer Axle Components
E 1002I,W, E 1202I,W, E1203I, E1322I,W, E 1462I,W - Dual Draw Key Design
Qty
Item Description Per Axle E1002I,W E1202I,W E1203I E1322I,W E1462I,W Notes
King Pin Kits
Kit w/ Presized Garlock Bushing (DX) 1 328349 328349 328348 328349 328349
Kit w/Bronze Bushing 1 328347 328347 328346 328347 328347
Kit w/DX10 Bushing Design for
Extended Bushing Life
1 503701 503701 - 503701 503701 503700 Top dead ctr
Kit w/DX10 Bushing Design for mounted ADB (Bulletin
Extended Bushing Life 503700 HAXL PNI 23)
1 Drawkey Hex Locknut 4 220HN103 All Models
2 Belleville Sprint Washer 8 1460HN100 All Models
3 Seal (Knuckle) 4 820518 All Models
4 Shim .005" A/R 817493 All Models
.010" A/R 817494 All Models
.030" A/R 817492 All Models
5 Drawkey Upper 2 160HP104-1 All Models
6 Drawkey Lower 2 160HP104-2 All Models
7 Thrust Bearing 2 220HC104 220HC104 971011 220HC104 220HC104
8 Beam 1 Refer to ID tag on assy
Stop Bolt Adapter Assy 2 120HM101 Incl. 9-11
9 Stop Bolt (30-50 degree) 2 101HM100-5 All Models
10 Stop Screw Nut 2 HN148 All Models
11 Adapter Nut 2 120HN100 All Models
12 Stop Screw 22-29 degree 2 818140 All Models
30-35 degree 2 816365 All Models
36-40 degree 2 816366 All Models
41-45 degree 2 816367 All Models
46-50 degree 2 816369 All Models
51-55 degree 2 816370 All Models
13 Stop Screw Nut 2 90208 All Models
14 Tie Rod Assy 1 See page 12
15 Tie Rod Clamp Assy 2 See page 12
16 Tie Rod Ends 2 See pages 12-13
17 Stamped Lock Nut 2 140HN105 All Models
18 Cotter Pin 2 HP115 All Models
19 Jam Nut 2 140HN104 All Models
20 D-Flat Washer 2 140HN103 All Models
21 Jam Nut Outer 2 815638 All Models
22 Retainer Washer 2 817134 All Models
23 Spindle Washer 2 815623 All Models
24 Jam Nut Inner 2 815622 All Models
25 Grease Fitting 4 819790 All Models
26 Knuckle Cap 4 971370 All Models
27 Foam Insert 4 971010 All Models
28 Bushing Presized Garlock 4 806334 806334 1320HD101 806334 806334
Bronze 4 1460HD100 1460HD100 1320HD100 1460HD100 1460HD100
DX10 2-4 - 1460HD103 - - 1460HD103 Top dead ctr requires two
DX10 2 - 1460HD104 - - - different length bushings
29 Knuckle Pin 2 1460SC102 1460SC102 1320SC100 1460SC102 1460SC102 1460SC103 (used w/TDC ADB)
Pin Sizes: 9.06" x 1.87" 9.06" x 1.87" 9.06" x 1.72" 9.06" x 1.87" 9.06" x 1.87"
30 Knuckle Assy 1 Refer to assy number on ID tag
31 Cotter Pin 2 HP102 All Models
