J300P-3

Slip Yoke Assemblies

LD & MD Driveshaft Style

Boot Kit Assy

Slip Yoke

C/L to End

C/L to Face

Lube

Dust Cap

Slip Yoke

Part Number

Assembly

of Spline

of Plug

Fitting

& Washer Kit

Plug Number

Order Separately

Style Part Number

Part of Slip Yoke Assembly

Important: See Safety Information in General Information Section (J300P-GI)

•

Part is discontinued  Part is available until supply is exhausted

Not sold separately

Important: See Safety Information in General Information Section (J300P-GI)

1330 SERIES (Con't)

SR: E-3.875 OTHERS E-3.625, D-1.062 USE KIT 5-213X,5-790X,5-812X

1.375-16 Spline

6.000

1.000

500174-1

D3E

3-68-23

—

SR 2-3-4681KX

6.000

1.000

500174-1

211121X

2-68-143

—

SR 2-3-7961KX

7.500

1.000

500174-1

211121X

2-68-28X

—

SR 2-3-12031KX

Relief valve in plug

7.500

1.000

—

3-68-23

—

SR 2-3-7481X•

D2M dust cap & washer kit, order separately

7.500

1.000

500174-1

211121X

3-68-23

—

SR 2-3-8041KX

1.378-31 Based On 32 Involute Spline

6.000

1.000

500174-1

211121X

2-68-143

—

SR 2-3-10571KX•

1.500-15 Based On 16 Spline

7.312

1.188

—

3-68-33

—

SR 2-3-10871X•

Used on driveshaft w/outboard slip

7.500

1.000

500174-1

211158X

3-68-33

—

SR 2-3-8111KX•

1.500-16 Spline

8.182

—

CV 211391X

Slip Yoke is a ball stud & sleeve assembly; 500174-1 lube fitting & D3A dust cap, order separate

1350 SERIES

E-3.875 D-1.188

USE KIT 5-178X OR 5-799X

1.375-15 Based On 16 Spline

6.810

1.190

500174-1

211121X

3-68-33

—

SR 3-3-2701KX

1.375-16 Spline

5.250

1.188

500174-1

D3E

3-68-33

—

SR 3-3-758KX

5.688

1.188

500174-1

D2C

3-68-33

—

SR 3-3-1421KX

5.812

1.188

500174-1

D3G

3-68-33

—

SR 3-3-1501KX

6.625

1.188

500174-1

D3G

3-68-33

—

SR 3-3-2591KX

1.377-31 Based On 32 Involute Spline

6.625

1.188

500174-1

D3F

3-68-33

—

SR 3-3-2471KX

1.390-30 Based On 31 Involute Spline

4.810

1.190

—

500166-22

—

SR 3-3-3001X

Use boot #40929 & clamps 40540-4 & 40540-3; order separately

5.240

1.190

—

211121X

3-68-23

—

SR 3-3-2861X

1.463-21 Based On 22 Involute Spline

7.310

1.160

—

500166-24

212094X

SR 3-3-6381X

Slip yoke barrel is tapered.

7.312

1.190

—

500166-24

212010X

SR 3-3-6201X

7.312

1.190

—

500166-24

212010X

SR 3-3-6981X

1.500-14 Based On 16 Spline

7.312

1.188

—

500166-24

212010X

SR 3-3-4781X

7.312

1.188

—

500166-24

211916X

SR 3-3-5461X

1.500-15 Based On 16 Spline

6.938

1.188

—

500166-24

212010X

SR 3-3-4651X

7.310

1.188

500174-1

211158X

3-68-33

—

SR 3-3-5921KX

7.312

1.188

500174-1

211158X

3-68-33

212010X

SR 3-3-2801KX
