Slip yoke assemblies for transmission applications – Spicer DRIVELINE COMPONENTS CATALOG SLIP YOKE ASSEMBLIES User Manual

Page 21

J300P-3

Slip Yoke Assemblies

For Transmission Applications

Important: See Safety Information in General Information Section (J300P-GI)

•

Part is discontinued  Part is available until supply is exhausted

Not sold separately

Slip Yoke

C/L to End

Ground Hub

Style

Plug

Assembly

End of Spline

Diameter

Depth

Part Number

Counterbore

1330 SERIES (Cont'd) SR: E-3.875 OTHERS E-3.625, D-1.062 USE KIT 5-213X,5-790X,5-812X

1.378-31 Based On 32 Involute Spline

6.760

1.885

—

2-68-143

2-3-12191X•

6.760

1.885

—

500166-24

2-3-13811X•

7.250

1.885

—

500166-22

2-3-14241X

Nickel Plated

7.720

1.885

—

500166-24

2-3-14831X

Nickel Plated

7.720

1.885

—

500166-24

2-3-13881X•

OEM Only

7.940

1.885

1.410

.220

500166-24

2-3-10791X

8.640

1.885

—

500166-22

2-3-14281X

Nickel Plated

1.390-30 Based On 31 Involute Spline

6.000

1.688

—

500166-22

2-3-6041X

7.000

1.885

—

500166-22

2-3-10201X

7.460

1.886

—

500166-22

2-3-12961X

C.V. Yoke-Nickel Plated

1.401-32 Based On 34 Involute Spline

8.465

1.770

—

500166-20

2-3-03207X

8.465

1.770

—

500166-20

5003207

5003207 was replaced by 2-3-03207X

1.406-32 Based On 34 Involute Spline

8.456

1.770

—

500166-22

2-3-04846X

8.456

1.770

—

500166-22

5004846

5004846 was replaced by 2-3-04846X

8.464

1.770

—

500166-22

3-3-08189X

8.465

1.771

1.438

.393

500166-22

2-3-15891X

8.465

1.771

1.438

.393

500166-22

2-3-04410X

8.465

1.771

1.438

.393

500166-22

5004410

5004410 was replaced by 2-3-04410X

1350 SERIES

E-3.875 D-1.188

USE KIT 5-178X OR 5-799X

1.176-26 Based On 27 Involute Spline

6.940

1.502

1.218

.410

2-68-23

3-3-4281X

6.940

1.502

1.218

.410

500166-20

3-3-3721X

1.201-20 Based On 23 Involute Spline

7.106

1.574

—

5004083•

OEM Only

1.230-20 Based On 23 Involute Spline

7.106

1.574

—

2-68-343

5016999•

OEM Only

1.284-29 Based On 30 Involute Spline

9.512

1.681

—

500166-22

5015498

OEM Only

9.519

1.680

—

500166-22

5016138

OEM Only

1.326-29 Based On 30 Involute Spline

6.630

1.680

—

500166-22

3-3-3931X

7.779

1.885

—

500166-22

5002231

5002231 was replaced by 3-3-02231X

7.779

1.885

—

500166-22

3-3-02231X
