Slip yoke assemblies for transmission applications – Spicer DRIVELINE COMPONENTS CATALOG SLIP YOKE ASSEMBLIES User Manual

Page 19

J300P-3

Slip Yoke Assemblies

For Transmission Applications

Important: See Safety Information in General Information Section (J300P-GI)

•

Part is discontinued  Part is available until supply is exhausted

Not sold separately

Slip Yoke

C/L to End

Ground Hub

Style

Plug

Assembly

End of Spline

Diameter

Depth

Part Number

Counterbore

1310 SERIES (Continued) E-3.469 D-1.062

USE KIT 5-153X, 5-785X, 5-810X

1.375-10 Spline

2.562

2.120

—

2-3-9021

Hub dia. not ground

1.377-30 Based On 32 Involute Spline

6.102

1.731

1.387

.394

500166-22

2-3-15961X

Counterbore at hub end

1.378-31 Based On 32 Involute Spline

4.880

1.885

—

500166-22

2-3-13131X

1.390-30 Based On 31 Involute Spline

7.000

1.684

—

500166-22

2-3-15631X•

1.397-31 Based On 32 Involute Spline

5.188

1.688

1.458

.880

500166-22

2-3-5281X

5.500

1.885

—

500166-22

2-3-10431X

1.403-21 Involute Spline

4.130

2.000

—

2-68-154

2-3-9811X

1.564-24 Involute Spline

4.125

2.000

—

2-68-154

2-3-9761X§

1330 SERIES

SR: E-3.875 OTHERS E-3.625, D-1.062 USE KIT 5-213X,5-790X,5-812X

1.113-24 Based On 25 Involute Spline

6.860

1.374

—

500166-20

2-3-15471X

Nickel plated yoke w/vibration dampener

6.860

1.374

—

500166-20

2-3-15461X

Nickel Plated

6.860

1.374

—

500166-20

2-3-13721X

1.158-25 Based On 26 Involute Spline

6.180

1.558

—

500166-20

2-3-15051X•

7.000

1.558

—

500166-20

2-3-14311X

Nickel Plated

1.176-26 Based On 27 Involute Spline

5.470

1.502

—

500166-20

2-3-12081X

5.470

1.502

1.218

.390

500166-20

2-3-12361X

W/c-bore and vibration dampener

5.470

1.502

1.218

.390

500166-20

2-3-12371X•

5.760

1.502

—

500166-20

2-3-13671X•

6.417

1.502

1.216

.590

500166-20

2-3-15751X•

6.760

1.502

1.217

.410

500166-20

2-3-11781X

6.760

1.502

1.217

.410

500166-20

5010254

5010254 was replaced by 2-3-11781X

6.760

1.502

1.217

.410

2-68-23

2-3-12051X

7.290

1.558

—

500166-20

2-3-14171X•

Nickel Plated

7.290

1.558

—

500166-20

2-3-14191X

1.177-26 Based On 27 Involute Spline

6.760

1.500

1.225

.300

2-68-23

5001433

5001433 was replaced by 2-3-01433X; Nickel Plated w/c’bore at end

6.760

1.502

1.217

.300

2-68-23

2-3-01433X

Nickel Plated w/c’bore at end
