J300P-3
Slip Yoke Assemblies
For Transmission Applications
23 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
Slip Yoke Slip Yoke
C/L to End Ground Hub Style Plug Assembly
End of Spline Diameter Diameter Depth Part Number Part Number
J R Counterbore
1410 SERIES E-4.438 D-1.188 USE KIT 5-160X OR 5-801X
1.284-29 Based On 30 Involute Spline
8.340 1.680 — — SR 500166-22 3-3-6121X
Nickel Plated
8.340 1.680 1.440 1.440 SR 500166-22 3-3-4181X
8.340 1.680 1.440 1.440 SR 500166-22 3-3-4851X
Nickel Plated
8.340 2.161 1.440 1.440 SR 500166-22 5002035•
8.340 2.161 1.440 1.440 SR 500166-22 3-3-02035X©
8.344 1.688 — — SR 500166-22 3-3-6131X
Nickel plated yoke w/vibration dampener
1.326-29 Based On 30 Involute Spline
8.340 1.680 1.440 1.440 SR 500166-22 3-3-3251X
8.340 1.680 1.440 1.440 SR 500166-22 3-3-3271X
Nickel Plated
1.378-30 Based On 32 Involute Spline
6.100 1.731 1.387 .394 SR 500166-22 3-3-04624X
6.100 1.731 1.387 .394 SR 500166-22 5004624
5004624 was replaced by 3-3-04624X
1.378-31 Based On 32 Involute Spline
6.940 1.885 — — SR 3-68-23 3-3-6471X•
6.940 1.885 — — SR 500166-24 3-3-6321X
6.940 1.885 — — SR 500166-24 3-3-6811X•
7.750 1.885 — — SR 500166-22 3-3-3811X
7.750 1.885 — — SR 500166-22 3-3-3891X
Nickel Plated
8.070 1.885 — — SR 500166-24 5001646
5001646 was replaced by 3-3-01646X; Nickel Plated
8.070 1.885 — — SR 500166-24 3-3-6421X
8.070 1.885 — — SR 500166-24 3-3-01646X
Nickel Plated
8.750 1.885 — — SR 500166-22 3-3-4401X
8.750 1.886 — — SR 500166-22 3-3-4211X
W/vibration dampener
1.390-30 Based On 31 Involute Spline
8.110 1.885 — — SR 500166-22 3-3-6001X•
Nickle Plated - OEM only
8.110 1.885 — — SR 500166-22 3-3-6661X
1.406-34 Involute Spline
8.465 1.770 — — SR 500166-22 3-3-18190X©
Nickel Plated
1.500-35 Based On 37 Involute Spline
6.102 1.888 1.535 .254 SR 500166-24 5013341
OEM Only
1.551-33 Based On 34 Involute Spline
8.110 2.086 — — SR 500166-26 3-3-7041X
Nickel Plated
1.615-30 Based On 31 Involute Spline
7.750 2.200 — — SR 500166-28 3-3-5631X
8.340 2.200 — — SR 500166-28 3-3-4391X
8.340 2.200 — — SR 500166-28 3-3-4131X
same as 3-3-4391x except w/vibration dampener
