Slip Yoke Assemblies

For Transmission Applications

Important: See Safety Information in General Information Section (J300P-GI)

•

Part is discontinued  Part is available until supply is exhausted

Not sold separately

Slip Yoke

C/L to End

Ground Hub

Style

Plug

Assembly

End of Spline

Diameter

Depth

Part Number

Counterbore

SPL55 SERIES

E-4.440 D-1.374

USE KIT 5-803X, 5-804X, SPL55-1X, SPL55-2X

1.615-30 Based On 31 Involute Spline

8.339

2.200

—

500166-28

55-3-21X

1.616-30 Based On 31 Involute Spline

8.339

2.200

—

500166-28

55-3-01672X

8.339

2.200

—

500166-28

5001672

5001672 was replaced by 55-3-01672X

1.748-33 Based On 34 Involute Spline

9.291

2.300

—

500166-29

3-3-17529X

Nickel Plated

9.291

2.300

—

500166-29

5017529

5017529 was replaced by 3-3-17529X; Nickel Plated

1210 SERIES

E-2.688 D-1.062

USE KIT 5-443X

1.113-24 Based On 25 Involute Spline

5.875

1.374

—

500166-20

2-3-10071X•

1310 SERIES

E-3.469 D-1.062

USE KIT 5-153X, 5-785X, 5-810X

1.005-22 Based On 24 Involute Spline

6.045

1.376

1.043

.390

500166-20

2-3-13461X

1.104-20 Based On 21 Involute Spline

6.000

1.496

—

500166-20

2-3-9701X

1.113-24 Based On 25 Involute Spline

6.500

1.375

—

500166-20

2-3-8431X

8.250

1.374

1.194

2.890

2-68-153

2-3-8891X•

1.123-24 Based On 26 Involute Spline

6.040

1.494

1.142

.390

500166-20

2-3-11731X

6.045

1.494

1.160

.390

500166-20

2-3-13891X

1.125-10 Spline

3.469

1.625

—

2-68-44

2-3-7501X

3.469

1.641

—

2-68-44

2-3-11551X•

1.158-25 Based On 26 Involute Spline

6.000

1.558

—

500166-20

2-3-8731X

6.000

1.558

—

500166-20

2-3-9781X

1.172-16 Spline

4.875

1.500

—

500166-20

2-3-1331X

1.176-26 Based On 27 Involute Spline

4.875

1.500

—

500166-20

2-3-4911X

4.891

1.500

1.260

.500

500166-20

2-3-9211X

Corvette w/o vibration dampener; C-bore @ Hub End

4.891

1.502

—

500166-20

2-3-10501X

5.469

1.500

—

500166-20

2-3-6081X
