Spicer DRIVELINE COMPONENTS CATALOG SLIP YOKE ASSEMBLIES - Manual (Page 5)

Important: See Safety Information in General Information Section (J300P-GI)
J300P-3
Slip Yoke Assemblies
LD & MD Driveshaft Style
5 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
Boot Kit Assy Slip Yoke
C/L to End C/L to Face Lube Dust Cap Slip Yoke Part Number Assembly
of Spline of Plug Fitting & Washer Kit Plug Number Order Separately Style Part Number
J F Part of Slip Yoke Assembly
1310 SERIES (Continued) E-3.469 D-1.062 USE KIT 5-153X, 5-785X, 5-810X
1.375-16 Spline (Continued)
6.471 — — — — — CV 2-3-7461X
500174-1 lube fitting & D2M dust cap, order separately
6.750 .875 500174-1 D2M 3-68-23 — SR 2-3-1931KX
6.812 1.500 500174-1 211121X 2-68-143 — SR 2-3-8001KX
6.875 1.500 500174-1 — 3-68-23 — SR 2-3-5221X
Use dust cap kit D3E for reverse slip applications
7.875 1.500 500174-1 — 3-68-23 — SR 2-3-5821X
Use dust cap kit D3E for reverse slip applications
7.875 1.500 500174-1 211121X 2-68-143 — SR 2-3-8021KX
1.377-31 Based On Involute 32 Spline
6.750 .875 500174-1 211121X 2-68-143 — SR 2-3-10261KX
6.750 .875 — — 500166-22 211600X SR 2-3-10801X•
1.378-31 Based On 32 Involute Spline
6.620 1.531 500174-1 D2N 2-68-134 — SR 2-3-7171KX
6.812 1.500 500174-1 211411X 2-68-143 — SR 2-3-10641KX•
6.812 1.500 — — 2-68-63 211600X SR 2-3-9371X•
1.390-30 Based On 31 Involute Spline
5.062 1.438 500174-1 211121X 3-68-23 — SR 2-3-8311X
Spec 4X4 axle yoke w/hole in plug
5.062 1.438 231330 2-86-298 500166-22 — SR 2-3-8481X
Spec 4X4 axle yoke w/lube fitting in yoke
5.062 1.438 — — 500166-22 — SR 2-3-8741X
Use boot #40465, clamps #40540-1,-2; I.S. snap ring style
1.500-16 Spline
2.906 .656 500174-1 D3F 2-68-64 — SR 2-3-7691KX
6.875 1.531 500174-1 D3A 3-68-33 — SR 2-3-6061KX
1330 SERIES SR: E-3.875 OTHERS E-3.625, D-1.062 USE KIT 5-213X,5-790X,5-812X
1.284-29 Based On 30 Involute Spline
6.600 1.100 — — 500166-22 — SR 2-3-13221X
Used on driveshaft w/outboard slip
1.338-18 Based On 20 Involute Spline
6.640 1.000 — — 500166-22 212094X SR 2-3-16221X
6.724 1.102 — — 500166-22 211932X SR 2-3-15651X
1.338-19 Based On 20 Involute Spline
6.700 1.000 — — 500166-22 212094X SR 2-3-13831X
1.375-14 Based On 16 Spline
6.720 1.102 — — 500166-22 211932X SR 2-3-14331X
7.039 1.417 — — 500166-22 211932X SR 2-3-06028X
7.039 1.417 — — 500166-22 211932X SR 5006028
5006028 was replaced by 2-3-06028X
1.375-15 Based On 16 Spline
5.410 1.060 — — 500166-22 211916X SR 2-3-13571X•
6.000 1.000 — — 500166-23 211916X SR 2-3-8921X
6.620 1.000 — — 500166-22 211932X SR 2-3-11991X•
211121X dust cap & washer kit, order separately
6.625 1.000 — 211121X 2-68-28X — SR 2-3-11491KX
6.625 1.000 — 211121X 500166-22 211932X SR 2-3-11991KX•
6.625 1.000 500174-1 211121X 3-68-23 — SR 2-3-7681KX
7.500 1.000 500174-1 211121X 3-68-23 211463X SR 2-3-8941KX•
