Spicer DRIVELINE COMPONENTS CATALOG SLIP YOKE ASSEMBLIES - Manual (Page 15)

Important: See Safety Information in General Information Section (J300P-GI)
J300P-3
Splined Sleeves
15 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
* = Tube Length
End of Spline Style Tube Yoke Mates w/ Butt Splined Sleeve Slinger Assembly
to Weld Part Number Part Number Diameter Detail Part Number Part Number
J Fits Tube/ F Slip Sleeve
1310 SERIES
1.375-16 Spline
5.030 4 2-28-3707X 211256X — — — 2-55-51•
Sleeve Only-No Assembly
3.002-22 Based On 23 Involute Spline
3.580 5 32-38-12 2-82-1901X 3.854 2-55-141 6.5-68-64 2-55-258X
Material: Aluminum
1330 SERIES
3.000-24 Spline
7.524 1 — 5004948 3.355 5003494 — 5005921
Alum slip jt. assy, used w/3.500 o.d. alum tube
3.002-22 Based On 23 Spline
4.910 5 — 2-82-1971X 3.815 5002371 6.5-68-64 2-55-02372X
Mat’l: alum, used w/4.500 o.d. alum tube
4.910 5 — 2-82-1971X 3.815 5002371 6.5-68-64 5002372
5002372 was replaced by 2-55-02372X; Mat’l: alum, used w/4.500 o.d. alum tube
3.002-22 Based On 23 Involute Spline
3.910 5 — 2-82-1971X 3.854 2-55-181 6.5-68-64 2-55-268X•
Mat’l: alum, used w/4.000 o.d. alum tube
4.910 1 — 2-82-1961 3.854 — — 2-55-278X
Mat’l: alum, used w/4.000 o.d. alum tube
1350 SERIES
3.000-24 Spline
6.275 5 — 5005288 4.888 5006299 — 5007951
Alum slip jt. assy. used w/4.500 o.d. alum tube
6.275 5 — 5005288 4.888 5006303 — 5007952
Alum slip jt. assy, used w/5.000 alum tube
1410 SERIES
1.750-16 Spline
4.410 3 211140X-* 3-82-781 2.594 3-55-33 4-68-143 3-55-38X
1550 SERIES
2.000-16 Spline
4.560 3 210833X-* 4-82-211 3.320 4-55-43 4-68-43 4-55-48X
1710 SERIES
2.500-16 Spline
5.720 3 211110X-* 6-82-1131-2 5.020 6-55-43 6.5-68-13 6-55-38X
1810 SERIES
3.000-16 Spline
7.750 3 211570X-* 6.5-82-451-1 5.757 8-55-103 6.5-68-23 8-55-113X
7.750 3 211180X-* 6.5-82-451-1 5.020 8-55-33 6.5-68-23 8-55-43X
