3.4.9 H
OW TO
A
SSOCIATE
C
HANNELS TO
P
ROVIDE A
K
EY AND
F
ILL
M
ODE
To associate 2 channels together for use with Key and Fill
operations, use the standard command of SHIFT + click or CTRL
+ click to select the channels required in Channel Explorer, then
use a right-click to see the contextual menu, and select the Fill
Key command from the menu.
The association will be shown in the Channel Explorer by an
icon on the Fill channel and an icon on the Key
channel and also be reflected in the title bar of the Control
panels. The first channel selected will become the Fill and the
second the Key.
52
