3.14 CONTROLLER AND PROTOCOL

SETTINGS

Port Device/Protocol p.7.1
RS422 #1 EVS Remote [F7]ID Type:
[F2]RS422 #2 EVS Remote ID LSM

[F3]RS422 #3 EVS Remote
[F4]RS422 #4 Sony BVW75
[F5]RS422 #5 Sony BVW75

[F6]RS422 #6 Touch Screen
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

This page is used to define what type of device/controller is connected to each

RS422 port of the server.

3.14.1 RS422

Value: EVS Remote
When working in XSense configuration, the first RS422 port must always be
connected to an EVS remote. No other possible selection

3.14.2 RS422

Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP, EVS
AVSP, EVS IPDP, Edit Rec, ---------

Default: EVS Remote

3.14.3 RS422

Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP, EVS
AVSP, EVS IPDP, Edit Rec, ---------
Default: EVS Remote

3.14.4 RS422

Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP, EVS
AVSP, EVS IPDP, Edit Rec, ---------

Default: Sony BVW75
