10.03.A XSense – Version 10.03 – Configuration Manual
EVS Broadcast Equipment SA – July 2010
66
3.13 EVS CONTROLLER SETTINGS
EVS Controller p.6.1
[F1]Effect duration for Take: 00s05fr
[F2]Fast jog : 20x
[F3]PGM Speed/Var Max : 50%
[F4]Lever engage mode : Direct
[F5]Second lever range : -100% <-> +100%
[F6]Recall Clip Toggle : Enable
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
3.13.1 E
FFECT
D
URATION FOR
T
AKE
Possible range: 00s00fr to 20s00fr. Default: 00s05fr
This parameter defines the duration of the transition when using the TAKE key to
chain 2 sequences in PGM+PRV mode.
3.13.2 F
AST
J
OG
Possible values: 01 to 20 times. Default: 20x
This parameter sets the increment of the jump when in Fast Jog mode.
3.13.3 P
GM
S
PEED
/V
AR
M
AX
Possible values: 1 – 400%. Default: 50%
During playback, if PGM Spd has been enabled in the secondary menu of the
Remote Panel, the lever range will be adapted so that the only playback value is
the one specified by this parameter in the setup (PGM Spd mode ON)
3.13.4 S
ECOND
L
EVER
R
ANGE
A secondary range is available to playback material at the following speed ranges:
-100% Î ±100% (default)
0 О 200%
-200% О±200%
0 О 400%
-400% О ±400%
To gain access to the secondary speed from the remote controller, press SHIFT +
LEVER/TAKE.
