XSense – Version 10.03 – Configuration Manual

EVS Broadcast Equipment SA – July 2010

Issue 10.3.A

The second lever range is also available when editing the speed of playlist clips.

3.13.5 R

ECALL CLIP TOGGLE

Possible values: Enable (default) / Disable

This option allows the operator to select the camera of a clip through the Function

keys. Pressing several times the F_ key browses to CAM A, CAM B, CAM C, CAM
D, CAM E and CAM F.

EVS Controller p.6.2
[F1]Record key : Start REC + Live

[F2]Pointing device : Tablet
[F3]VGA & RMT Sync : No

[F4]PGM/PRV Mode : Enable

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

3.13.6 R

ECORD

Possible values: Start REC+Live (default) / Live

This parameter changes the function of the RECORD key on the remote:

•

Start REC+Live: Pressing the RECORD key starts the record process and

switches to LIVE mode.

•

Live: Pressing the RECORD key only switches to last recorded picture, but the

record is not restarted if it has been previously stopped by the operator.

3.13.7 P

OINTING

EVICE

Possible values: Tablet (default) / Touch Screen

This setting initializes the Tablet or the Touch Screen. If the tablet is not properly
calibrated, use this function to re-initialize it. If using the Touch Screen, this one

must always be connected to RS422 port #6 of the server, and defined as such at
page 7.1 of the setup.

3.13.8 VGA

RMT

YNC

Possible values: No, Yes, Server Nbr

This parameter selects whether and how the current clips machine, page and bank
of VGA screens and EVS Remote Panel must be synchronized.

Value Meaning

No
(Default)

Clip machine, page and bank can be selected independently on the
VGA screen and on the EVS Remote Panel.
