Issue 3.1.C Xedio Suite Version 3.1 - User Manual – Xedio Manager
EVS Broadcast Equipment – January 2011
82
Timeline
Show Default Audio
Channel Buttons When selected: displays the Default Audio Channel
buttons.
Show TC In Out When selected: displays the timecodes (IN and OUT) in
the timeline blocks.
Tag_External
Graphics When selected: enables the External Graphics tab in tag
properties dialog box.
Tag_Logo Insertion When selected: enables the Logo Insertion tab in tag
properties dialog box.
Tag_Viz When selected: enables the Viz tab in tag properties
dialog box.
Tag Default Duration Field to enter the default tags duration.
Tag Label List When selected: uses label list for tags.
Otherwise, free text is used.
Tag Properties When selected: enables the Tag Properties dialog box
and Adds Tag contextual menu
Use Tag Labels When selected: enables the Label field in the External
Graphics tab of the Tags dialog box.
Use Tag Templates When selected: enables the Template field in the External
Graphics tab of the Tags dialog box.
Video Auto FX When selected: enables automatic video transition effect.
Video Color Dur Field to enter the length of the clip created with the ‘color
insertion tool’.
Video Color Ins Option list to select the color of the clip created with the
‘color insertion tool’.
Video Effects When selected: enables video transition effects
adjustments.
TL Buttons
Afx When selected: displays the AFX button above the
timeline.
Align Left When selected: displays the Align Left button above the
timeline.
Align Right When selected: displays the Align Right button above the
timeline.
