GX server – Version 1.0 – User’s Manual
EVS Broadcast Equipment – February 2011
Issue 1.0.C
47
5.5.3 G
ENERAL
P
RINCIPLES
A
BOUT
TC F
IELDS ON THE
GX
S
ERVER
The following general principles are applicable to the various IN, OUT, TC fields
and other fields displayed in the Edit GX Clip window and the GX Clips tab:
• The IN and OUT points, and other TC-related fields defined as general, video
and audio settings for the GX clip refer to the timecodes defined on the raw
materials. In other words, the reference timecode is always TC 00:00:00:00 of
the raw material.
• The start timecode of the GX clip as it is played out and displayed to the
external controllers is always 00:00:00:00.
• All frames of a GX clip are played out. In other words, a GX clip that lasts 2
seconds will be played from TC 00:00:00:00 to TC 00:00:01:24 (for 50Hz clips)
or TC 00:00:01:29 (for drop-frame 60Hz clips) if the corresponding raw
material is played out from start to end.
• The GX clip length corresponds to the length of the longest raw material
(either audio or video), including possible loops.
5.5.4 G
ENERAL
S
ETTINGS IN THE
E
DIT
GX C
LIPS
W
INDOW
Important
When you modify a field value in the
E
dit GX Clip window, you always
need to press ENTER to validate the change.
S
TATUS
F
IELD
The Status field gives the status of the GX clip on the server. The possible
statuses in the Edit GX Clip window are:
•
The GX clip is defined in the database, but is not uploaded on the GX Clips
drive.
•
The GX clip is defined in the database, and is being uploaded on the GX Clips
drive to be ready for playback.
•
The GX clip is defined in the database, and uploaded on the GX Clips drive.
