Issue 1.0.C

GX server – Version 1.0 – User’s Manual

EVS Broadcast Equipment – February 2011

6

2.2.3 F

RONT

P

ANEL

DVD Player

Server activity indicator

(orange HDD light)

Power indicator

(green PWR light)

USB

connector

Power

switch

eSata

connector

2.2.4 R

EAR

P

ANEL

Fill

Mouse

connector

USB

Power

Supplies

Keyboard

connector

Key

N/A

N/A

Genlock

N/A

N/A

N/A

RS422

GigE

Ethernet

GigE

Ethernet

VGA

Note
The two connectors labeled IN1 and IN2 (on the right of the Fill and Key

connectors) are not currently used.
