GX server – Version 1.0 – User’s Manual
EVS Broadcast Equipment – February 2011
Issue 1.0.C
27
5.2 MANAGING DRIVES AND FOLDERS
Before selecting and importing the source files, you need to connect and point to
the drives that contain the source files.
5.2.1 D
RIVE
T
REE
S
TRUCTURE
The drives and folders that contain the source files are displayed on the drive tree
structure (left part of the Import area):
5.2.2 D
RIVE
D
ISPLAY
The removable drives connected to the GX server (USB, eSata) and the DVD
drives are automatically displayed in the drive tree structure. The drive letter
assigned and the drive name are displayed.
You need to manually define the local or network drives to display them in the
drive tree structure. You also need to disconnect them manually when you want to
hide them.
The Raw Materials drive, which contains the imported files, is automatically
displayed in the drive tree structure.
5.2.3 H
OW TO
D
ISPLAY
F
OLDER
S
TRUCTURE AND
S
OURCE
F
ILES
To view or hide the folder structure below a given driver/folder, click the arrow in
front of this driver/folder:
To view the source files available in a given drive or folder, click the drive or
folder name:
