Issue 1.0.C GX server – Version 1.0 – User’s Manual
EVS Broadcast Equipment – February 2011
30
Field Name Description Values
Video
Standard
Video standard used in the
graphic file sequence. Not
applicable to audio files.
When a video standard can
have two different field
rates, you can select
another field rate than the
default one.
The value for video sequences can
be one of these:
• SD PAL
• SD NTSC DF or NDF
• 1080i 50Hz
• 1080i 59.94Hz DF or NDF
• 720p 50Hz
• 720p 59.94Hz DF or NDF
Audio
Association
Select from the list the
audio file you want to
associate to the graphic file
sequence.
The audio files available in the drop-
down field are:
• Audio files already copied to the
Raw Materials drive
• Audio files selected to be copied
to the Raw Materials drive
Progress Progress bar to show the
progress of the copy to the
Raw Materials drive
The progress bar displays:
• The percentage of the file that
has already copied during the
import process
• ‘Completed’ once the import
process is finished.
• ‘None’ when the file has not been
imported last.
• ‘Error’ if there was an error
during the import. The tooltip
provides information on the given
error.
5.3.3 H
OW TO
I
MPORT
F
ILES ON THE
GX S
ERVER
During the import process, the selected files are imported to the Raw Materials
drive of the GX server.
Note
Using the Direct Online import option, you can also upload the files
directly to the GX Clips drive with predefined playout settings. In this
case, they would directly be ready for playout.
