Table 1-2. Rear Panel Description
1
Current Shunt Terminals
5
Program Out BNC Female Connector
2
RS-232/422 25-pin Female D-sub
Connector
6
Dual Magnet Station 25-pin Female
D-sub Connectors
3
IEEE-488 Female Connector
7
Dual Auxiliary LHe Level/Temp 9-pin
Male D-sub Connectors
4
Quench I/O 9-pin Female D-sub
Connector
8
Input Power IEC-320 Male Connector
1.3
R
ear P
a
nel
Layo
ut
