Page 27
24
100S General Purpose Reference Manual
Troubleshooting
Error Messages (Keypad Test)
The messages below indicate that a problem was found during the key-
pad test at startup. If an error message appears, turn the system off,
press the appropriate key to release it back into position, and then re-
start the system. (Or you can press the
CLEAR
key to clear the error
message.) If the key does not work during normal operation, contact
your distributor for repair/replacement procedures.
SETUP
key
E11
MM
key
X
key
7
key
RAD/DIA
key
ABS/INCR
key
9
key
8
key
ZERO
key for the
X axis
6
key
ZERO
key for the
Z axis
5
key
4
key
1 Axis - X key
2 & 3 Axis - Y key
CLEAR
key
3
key
2
key
1
key
1 Axis - ZERO key (X)
2 & 3 Axis - ZERO key (Y)
±
key
ENTER
key
0
key
Decimal point (.)
key
Z
key
E38
E12
E15
E16
E18
E21
E25
E26
E28
E31
E33
E35
E36
E41
E45
E46
E48
E51
E54
E55
E56
E57
E58
