General Wiring Procedure
• Check that the MILLPWR system is powered down and disconnected
from its power source. Check that there is no power to the AMI.
• Remove the cover from the AMI.
• Insert a 0.17" to 0.47" diameter cable (with 24 -16 AWG maximum
wires) through the liquid tight strain relief that’s nearest the connector
you are planning to use (refer to Figure 10).
• Tighten the strain relief until the cable is securely in place.
• Cut the cable to length, then strip approximately 3/8” insulation from the
end of each wire.
• Loosen the appropriate connector screws, then insert the wires into
the connectors (refer to Figure 11).
• Tighten the screws. Ensure the wire has been adequately clamped by
applying a slight “tug”.
• After all of the wires are properly connected, reinstall the AMI cover and
insert rubber plugs into the unused holes.
The steps below explain the general procedure for wiring any device to the
connections on the AMI.
Refer to Figure 1 (page 4) for the location of each AMI and Emergency
Stop (E-Stop) input and output connection. Also refer to the AMI System
Overview section for common applications and descriptions of each connec-
tion.
All wiring should be performed by a qualified electrician.
