AMI Reference Manual 17
AMI Installation
The installation procedure is divided into three sections—Connecting to
MILLPWR , General Wiring Procedure, and Connecting to a Power Source.
Refer to the General Wiring Procedure section anytime you are installing a
new input or output device.
Unless indicated otherwise, each section applies to both AMI versions (115V
and 230V).
• Power down the MILLPWR system and disconnect it from its power source.
• Using four (4) 5/16"-18 machine screws, install the AMI in a convenient
location on or near the machine, within close proximity of the
MILLPWR
operator console. Ensure that both the communication cable and the power
cable, for 115V systems, will reach the
MILLPWR. If the AMI is being
installed on the machine, check that both are properly grounded. (Use star-
toothed washers if necessary).
• Connect one end of the interface cable to the connector located on the
AMI (refer to Figure 8). Tighten the two screws on the connector housing.
• Connect the opposite end of the cable to the AMI connector located on the
rear of the
MILLPWR operator console (refer to Figure 9). Tighten the two
screws on the connector housing.
• Proceed to the General Wiring Procedure section (page 18).
All wiring should be performed by a qualified electrician.
Connecting to MILLPWR
