8.5. Get the Current Setting of the Contactless Interface

Step 1) Get Status Command
<< FF 00 00 00 02 D4 04
>> D5 05 [Err] [Field] [NbTg] [Tg] [BrRx] [BrTx] [Type] 80 90 00

Or if no tag is in the field
>> D5 05 00 00 00 80 90 00

[Err] is an error code corresponding to the latest error detected.
Field indicates if an external RF field is present and detected (Field = 0x01) or not (Field = 0x00).

[NbTg] is the number of targets. The default value is 1.

[Tg]: logical number

[BrRx] : bit rate in reception
 0x00 : 106 kbps
 0x01 : 212 kbps
 0x02 : 424 kbps

[BrTx] : bit rate in transmission
 0x00 : 106 kbps
 0x01 : 212 kbps
 0x02 : 424 kbps

[Type ]: modulation type
 0x00 : ISO14443 or Mifare®
 0x10 : FeliCa™
 0x01 : Active mode
 0x02 : Innovision Jewel® tag
