8.1. How to Access PCSC-Compliant Tags (ISO 14443-4)?
Basically, all ISO 14443-4 compliant cards (PICCs) would understand the ISO 7816-4 APDUs. The
AET62 Reader just has to communicate with the ISO 14443-4 compliant cards through exchanging
ISO 7816-4 APDUs and Responses. AET62 will handle the ISO 14443 Parts 1-4 Protocols internally.
Mifare 1K, 4K, MINI and Ultralight tags are supported through the T=CL emulation. Just simply treat
the Mifare tags as standard ISO 14443-4 tags. For more information, please refer to topic “PICC
Commands for Mifare Classic Memory Tags”.
Command Class INS P1 P2 Lc
Data
In
Le
ISO 7816
Part 4
Command
Length
of the
Data
In
Expected
length
of the
Response
Data
Table 44: ISO 7816-4 APDU Format
Response Data Out
Result Response Data SW1 SW2
Table 45: ISO 7816-4 Response Format (Data + 2 Bytes)
Results SW1 SW2 Meaning
Success 90 00 The operation is completed successfully.
Error
63 00 The operation is failed.
Table 46: Common ISO 7816-4 Response Codes
Typical sequence may be:
-
Present the Tag and Connect the PICC Interface
- Read / Update the memory of the tag
Step 1) Connect the Tag
Step 2) Send an APDU, Get Challenge.
<< 00 84 00 00 08
>> 1A F7 F3 1B CD 2B A9 58 [90 00]
Hint:
For ISO14443-4 Type A tags, the ATS can be obtained by using the APDU “FF CA 00 00 01”
