Acroprint timeQplus Biometric (V2) TQ100 Terminal User Manual
Page 38
Level-1 Menu
Level-2 Menu
Level-3 Menu
timeQplus BIOMETRIC™ Terminal User Manual
7
38
timeQplus BIOMETRIC™ Terminal User Manual
3.1 Data Management
With Data Management option highlighted, press OK to access
Data Management level-2 menu and browse through the seven items
available. Some of the items have corresponding sub-items, the level-3
menu, as shown below:
Data Management
User
Registration
Administrator
Registration
Sensitivity
Level Setting
Delete Registration Data
View Punches
View Admin Record
Delete All Records
Fingerprint
Password
Fingerprint
or Password
Sensitivity
User Setting
Global Setting
PIN
Definition
1
TCP_TX+
2
TCP_TX-
3
TCP_RX+
4
5
6
TCP_RX-
7
RS485A
8
RS485B
8.2 RJ45 Interface
The RJ45 interface provides RS485 and Ethernet communication.
The wiring diagram of the supplied RJ45 connection cable is as follows:
