HandPunch 3000/4000 Manual
29
The HandReader is available with an optional internal Ethernet
communications module for TCP/IP communications. The wiring must
conform to 10BaseT standards. Typically, network wiring terminates at the
HandReader with a standard RJ-45 modular jack. The cable from the jack to
the HandReader is not provided with the Ethernet option. The IP address,
Gateway, and Host Bits are entered at the HandReader in the SET SERIAL
menu. Ethernet HandReaders may be networked with up to 31 non-Ethernet
HandReaders using RS-422 twisted pair cable. Refer to the Ethernet
application note (available from Schlage Biometrics) for detailed information.
A serial printer can be connected to a HandReader. A printer connected to a
remote HandReader will print only the events that occur at that HandReader.
Schlage Biometrics Inc. does not supply serial printers. Refer to the Printer
String application note (available from Schlage Biometrics) for detailed
information.
Remote
HandReader
Connected
to a Host PC
via Optional
Ethernet
Printer
