FPC 6120

12.1” Industrial fanless Panel PC

1.2.2 REAR PANEL

The rear panel provides access to a fan ventilation vent and four retention screw holes that
support a wall-mounting bracket. Figure 1-3 shows the retention screw holes of the FPC6120.

1.2.3 BOTTOM PANEL

The following is a list of the bottom panel peripheral device connectors on the

FPC6120. Diagrams for each other models are shown below.

1 x RS-232/422/485 port

2 x RS-232 ports

3 x Audio jacks (Line-in, Line-out and MIC-in)

1 x PS/2 keyboard/mouse connector

1 x AC power adapter connector

1 x VGA connector

2 x RJ-45 GbE connector

2 x USB 2.0 connectors

1 x CompactFlash® slot

1 x Power switch
